Relays Series
AZSR1160
Category
Solar-Relais
Switching Voltage (max.)
690VAC
Switching Current (max.)
160A
Switched Power (max.)
110.400 VA
110.400 VA
Nominal Coil Voltage
6 up to 48 VDC
6 up to 48 VDC
Nominal Coil Power
3,0 W
3,0 W
Contact Configuration
1 Form A (SPST/NO)
Type of Enclosure
Flux proof
Contact Gap
3,6mm
Dimensions L x W x H
62 x 63,3 x 41,7 mm
