Relays Series
AZ944
Category
Power Relay
Switching Voltage (max.)
250VAC
Switching Current (max.)
16A
Switched Power (max.)
2.000 VA
2.000 VA
300 W
Nominal Coil Voltage
5 up to 100 VDC
5 up to 100 VDC
Nominal Coil Power
from 128 mW
from 128 mW
Contact Configuration
1 Form A (SPST/NO)
Type of Enclosure
Flux proof
Contact Gap
-
Dimensions L x W x H
22 x 16 x 10,5 mm
