Relays Series
AZ832
Category
Signal Relay
Switching Voltage (max.)
125VAC
Switching Current (max.)
3A
Switched Power (max.)
250 VA
250 VA
60 W
Nominal Coil Voltage
3 up to 48 VDC
3 up to 48 VDC
Nominal Coil Power
from 150 mW
from 150 mW
Contact Configuration
2 Form C (DPDT)
Type of Enclosure
Epoxy sealed
Contact Gap
-
Dimensions L x W x H
20,2 x 10,2 x 10,6 mm
